SHG-2UJ

· High torque
· Zero Backlash
· Accuracy <1 arc-min (most sizes)
· High torsional stiffness
· Robust cross roller output bearing
· Output flange for direct mounting of load

Catalog

DXF CAD Files

PDF Drawings

3D CAD Files

Don't see what you need or not sure where to start?

Our team can help you find the right gear for your application!

Compare Products Your current units are metric. Change to english.

Part Number Ratio Rated Torque L50 Limit for Repeated Peak Torque Limit for Momentary Peak Torque
Compare Products Nm Nm Nm

Loading...

Part Number Ratio Rated Torque L50 Limit for Repeated Peak Torque Limit for Momentary Peak Torque
Compare Products Nm Nm Nm
Sort Sort
Hide
Sort
Hide
Sort
Hide
Sort
Hide
Selections
to
to
to
to
Select All   Select None
SHG-14-50-2UJ 50 7 23 46
SHG-14-80-2UJ 80 10 30 61
SHG-14-100-2UJ 100 10 36 70
SHG-17-50-2UJ 50 21 44 91
SHG-17-80-2UJ 80 29 56 113
SHG-17-100-2UJ 100 31 70 143
SHG-17-120-2UJ 120 31 70 112
SHG-20-50-2UJ 50 33 73 127
SHG-20-80-2UJ 80 44 96 165
SHG-20-100-2UJ 100 52 107 191
SHG-20-120-2UJ 120 52 113 191
SHG-20-160-2UJ 160 52 120 191
SHG-25-50-2UJ 50 51 127 242
SHG-25-80-2UJ 80 82 178 332
SHG-25-100-2UJ 100 87 204 369
SHG-25-120-2UJ 120 87 217 395
SHG-25-160-2UJ 160 87 229 408
SHG-32-50-2UJ 50 99 281 497
SHG-32-80-2UJ 80 153 395 738
SHG-32-100-2UJ 100 178 433 841
SHG-32-120-2UJ 120 178 459 892
SHG-32-160-2UJ 160 178 484 892
SHG-40-50-2UJ 50 178 523 892
SHG-40-80-2UJ 80 268 675 1,270
SHG-40-100-2UJ 100 345 738 1,400
SHG-40-120-2UJ 120 382 802 1,530
SHG-40-160-2UJ 160 382 841 1,530
SHG-45-50-2UJ 50 229 650 1,235
SHG-45-80-2UJ 80 407 918 1,651
SHG-45-100-2UJ 100 459 982 2,041
SHG-45-120-2UJ 120 523 1,070 2,288
SHG-45-160-2UJ 160 523 1,147 2,483
SHG-50-80-2UJ 80 484 1,223 2,418
SHG-50-100-2UJ 100 611 1,274 2,678
SHG-50-120-2UJ 120 688 1,404 2,678
SHG-50-160-2UJ 160 688 1,534 3,185
SHG-58-80-2UJ 80 714 1,924 3,185
SHG-58-100-2UJ 100 905 2,067 4,134
SHG-58-120-2UJ 120 969 2,236 4,329
SHG-58-160-2UJ 160 969 2,392 4,459
SHG-65-80-2UJ 80 969 2,743 4,836
SHG-65-100-2UJ 100 1,236 2,990 6,175
SHG-65-120-2UJ 120 1,236 3,263 6,175
SHG-65-160-2UJ 160 1,236 3,419 6,175
